Coaxial Cables RG, single shielded

Details



Subminiature Coaxial Cables SM

Details



Coaxial Cables RG, double shielded

Details



Low-noise Coaxial Cables RGL

Details

Art.-Nr.

RG coaxial cable, single shielded



Conductor: 1 – Steel wire with silver-plated copper coating (SCCS) or silver-plated copper (SPC)
Dielectric: 2 – Polytetrafluoroethylene (PTFE)
Shielding: 3 – Braided, silver-plated copper (SPC)
Sheath: 4 – Fluorinated ethylene propylene (FEP)
Color: transparent brown
Temperature range: -55 bis 200 ˚C
Conformity: RoHS, REACH



For Industrial applications

Item-Number Type Impe-dance Dimensions Weight Electrical Properties
Conductor Dielectric Shielding Sheath Voltage Max. Capacity Minimum Bending Radius (mm) Frequency max, Power Electrical attenuation
W Ω Number x Ø

[mm]

 Ø

[mm]

 Ø

[mm]

 Ø

[mm]

 Ø

[mm]



[g/m]



[VAC]



[pF/m]



[MHz]



[W]

 [db/100 m]
KORG142 RG 142 50 1 x 0,94 0,94 2,95 innen 4,80 80 1400 95 25 30 2373 7
SPC 3,50 100 1300 13
aussen 400 650 26
4,10 1000 411 42
2500 260 69
KORG178 RG 178 50 7 x 0,10 0,30 0,85 1,30 1,75 9 500 94 10 30 274 25
SPC 100 150 46
400 75 93
1000 47 148
2500 30 237
KORG179 RG 179 75 7 x 0,10 0,30 1,60 2,05 2,50 16 900 63 15 30 511 15
SPC 100 280 28
400 140 56
1000 89 86
2500 56 144
KORG316 RG 316 50 7 x 0,18 0,54 1,56 2,00 2,45 17 900 94 15 30 621 15
SPC 100 340 27
400 170 54
1000 108 86
2500 68 139
KORG400 RG 400 50 19 x 0,20 0,98 2,95 innen 4,80 70 1,400 94 25 30 2008 39
SPC 3,50 100 1100 8
aussen 400 550 15
4,10 1000 348 31
2500 220



For Military Applications

Item-Number Type Impe-

dance

 Dimensions Weight Electrical Properties
Conductor Dielectric Shielding Sheath Voltage max,

Capacity

 Minimum Bending Radius (mm) Fre-

quency

 max,

Power

 Electrical attenuation
W Ω Number x Ø

[mm]

 Ø

[mm]

 Ø

[mm]

 Ø

[mm]

 Ø

[mm]



[g/m]



[VAC]



[pF/m]



[MHz]



[W]

 ,

[db/100m]
KORG142M RG1 42 M 50 1 x 0,94 0,94 2,95 innen 4,80 80 1400 95 25 30 2373 7
SCCS 3,50 100 1300 13
aussen 400 650 26
4,10 1000 411 42
2500 260 69
KORG178M RG 178 M 50 7 x 0,10 0,30 0,85 1,30 1,75 9 500 94 10 30 274 25
weiss oder schwarz SCCS 100 150 46
400 75 93
1000 47 148
2500 30 237
KORG303M RG 303 M 50 1 x 0,94 0,94 2,95 3,55 4,32 45 1,400 94 25 30 2045 7
SCCS 100 1120 13
400 560 26
1000 354 42
3000 224 69
KORG304M RG3 04 M 1 x 1,50 1,50 4,70 innen 7,10 130 2200 94 40 30 4382 5
SCCS 5,40 100 2400 9
aussen 400 1200 18
6,10 1000 759 30
2500 480 49
KORG316M RG 316 M 50 7 x 0,18 0,54 1,56 2,00 2,45 17 900 94 15 30 621 15
schwarz oder weiss SCCS 100 340 27
400 170 54
1000 108 86
2500 68 139
KORG393M RG 393 M 50 7 x 0,80 2,43 7,24 innen 10,10 180 1900 95 50 30 6573 4
SPC 8,00 100 3600 7
aussen 400 1800 14
8,70 1000 1138 23
2500 720 39
KORG400M RG 400 M 50 19 x 0,20 0,98 2,95 innen 5,10 55 1,400 95 25 30 2008 39
SPC 3,50 100 1100 8
aussen 400 550 15
4,10 1000 348 31
2500 220





Subminiatur – Coaxial Cable SM



Conductor: 1 – Silver-plated, high-strength copper alloy (HSA) or silver-plated copper
Dielectric: 2 – Polytetrafluoroethylene (PTFE)
Shielding: 3 – Braided, silver-plated copper (SPC)
Sheath: 4 – Fluorethylene propylene (FEP)
Color: transparent
Temperatur Range: -55 bis 200 ˚C
Conformity: RoHS, REACH



Item – Number Type Impe-dance Dimensions Weight Electrical Properties
Conductor Dielectric Shielding Sheath Voltage max, Capacity Fre- quency max, Power Electrical attenuation
Numberl x Ø Ø] Ø Ø Ø
W Ω [mm] [mm] [mm] [mm] [mm] [g/m] [VAC] [pF/m] [MHz] [W] [db/100 m]
KOSM50 SM50 50 1 x 0,16 0,16 0,52 0,80 1,00 3 400 86 30 117 36
HSA 100 64 65
400 32 130
1000 20 207
2500 13 329
KOSM75 SM75 75 1x 0,10 0,10 0,52 0,80 1,00 3 600 64 30 117 36
HSA 100 64 65
400 32 130
1000 20 207
2500 13 329
KOSM95 SM95 95 1x 0,10 0,10 0,95 1,20 1,40 5 600 50 30 219 26
SPC 100 120 47
400 60 95
1000 38 151
2500 24 242





Coaxial Cable RG, double shielded



Conductor: 1 – Steel wire with silver-plated copper coating (SCCS)
Dielectric: 2 – Polytetrafluorethylene (PTFE)
Inside-Shielding: 3 – Braided, silver-plated copper (SPC)
Outside-Shielding: 4 – Braided silver-plated copper (SPC)
Sheath: 5 – Fluorethylenpropylene (FEP)
Color: transparent
Temperature Range: -55 bis 200 °C
Conformity: RoHS, REACH



For Industrial Applications

Item – Number Type Impe- dance Dimensions Weight Electrical Properties
Conductor Dielecric Shielding Sheath Voltage max, Capacity Minimum Bending Radius (mm) Fre-quency max, Power Electrical attenuation
Number x Ø Ø Ø Ø Ø]
W Ω [mm] [mm] [mm] [mm] [mm] [g/m] [VAC] [pF/m] [mm] [MHz] [W] [db/100 m]
KORGD179 RGD 179 50 7 x 0,10 0,30 1,60 innen 3,0 23 900 63 15 30 511 15
SCCS 2,05 100 280 28
aussen 400 140 56
2,50 1000 89 86
2500 56 144
KORGD180 RGD 180 95 7 x 0,10 0,30 2,60 innen 4,10 39 ,000 50 25 30 803 12
SCCS 3,05 100 440 21
aussen 400 220 43
3,50 1000 139 69
2500 88 112
KORGD316 RGD 316 50 7 x 0,17 0,51 1,52 innen 2,90 27 900 94 15 30 621 15
SCCS 2,00 100 340 27
aussen 400 170 54
2,40 1000 108 86
2500 68 139



For Military Applications

Item – Number Type Impe-dance Dimensions Weight Electrical Properties
Conductor Dielectric Shielding Sheath Voltage max, Capacity Minimum Bending Radius (mm) Fre- quency max, Power Electrical attenuation
Number x Ø Ø Ø Ø Ø]
W Ω [mm] [mm] [mm] [mm] [mm] [g/m] [VAC] [pF/m] [mm] [MHz] [W] [db/100 m]
KORGD178M RGD 178 M 95 7 x 0,17 0,30 0,87 innen 2,25 14 500 94 15 30 274 25
            21,30           100 150 46
            aussen           400 75 93
            1,74           1000 47 148
                        2500 30 237
KORGD179M RGD 179 M 75 7 x 0,10 0,30 1,60 innen 3,0 23 900 63 1515 30 511 15
            2,05           100 280 28
            aussen           400 140 56
            2,50           1000 89 86
                        2500 56 144
KORGD180M RGD 180 M 95 7 x 0,10 0,30 2,60 innen 4,10 39 ,000 50 25 30 803 12
            3,05           100 440 21
            aussen           400 220 43
            3,50           1000 139 69
                        2500 88 112
KORGD316M RGD 316 M 50 7 x 0,17 0,51 1,52 innen 2,90 27 900 94 15 30 621 15
            2,00           100 340 27
            aussen           400 170 54
            2,40           1000 108 86
                        2500 68 139





Low-Noise- Coaxial Cable RGL



Conductor: 1 – Silver-plated, copper-coated steel wire (SCCS) or silver-plated,
high-strength copper alloy (HSA) or silver-plated copper wire (SPC)
Dielectric: 2 – Polytetrafluorethylene (PTFE) avec semiconductive layer LS
(low noise coating)
Shielding: 3 – Braided, silver-plated copper (SPC)
Sheath: 4 – Fluorethylenpropylene (FEP)
Color: noir
Temperatur Range: -55 bis 200 °C
Conformity: RoHS, REACH



Item – Number Type Impe- dance Dimensions Weight Electrical Properties Minimum Bending Radius (mm)
Conductor Dielectric Shielding Sheathl max. Power max. Capacity


W Ω

 Number x Ø

[mm]

 Ø

[mm]

 Ø

[mm]

 Ø

[mm]

 Ø

[mm]



[g/m]



[W]



[pF/m]



[mm]
KORGL179 RGL 179 75 7 x 0,10 0,30 1,60 2,05 2,54 16 900 75 20
LS: 1,62
KORGL187 RGL187 75 7 x 0,10 0,30 1,60 2,05 2,69 16 900 75 20
LS: 1,62
KORGL196 RGL196 50 7 x 0,10 0,30 0,89 1,35 2,00 9 500 105 20
LS: 0,91
KORGL316 RGL 316 50 7 x 0,18 0,51 1,56 2,00 2,49 15 900 105 20
LS: 1,58
KORGL400 RGL400 50 19 x 0,20 0,98 2,98 3,55 4,95 65 1400 105 30
SPC LS: 3,00 4,10
KOSML50 SML 50 50 1 X 0,16 0,16 0,52 0,80 1,00 3 400 105 5
HSA LS; 0,54
